LM2940CS-5.0 Real Image LM2940CS-5.0 real image1228 LM2940CS-5.0 Real Image1 LM2940CS-5.0 Real Image2
Same model may have multiple batches, images only for reference.
LM2940CS-5.0 Real Image LM2940CS-5.0 real image1228 LM2940CS-5.0 Real Image1 LM2940CS-5.0 Real Image2
LM2940CS-5.0 Real Image LM2940CS-5.0 real image1228 LM2940CS-5.0 Real Image1 LM2940CS-5.0 Real Image2
Same model may have multiple batches, images only for reference.

LM2940CS-5.0

Part No LM2940CS-5.0
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 1A DDPAK
Datasheet
LM2940CS-5.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 0.8V @ 1A
Output Current 1A
Operating Supply Current 10mA to 15mA
PSRR 64dB (120Hz)
Control Protection Features Over Current, Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.5V @ 1A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 082673-LM2940CS-5.0
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian LM2940CS-5.0 CAD Model

Description

The LM2940CS-5.0 is a low dropout voltage regulator designed and manufactured by Texas Instruments, a global leader in semiconductor technology.

  • Type: Fixed voltage regulator
  • Output: 5.0 volts
  • Output Current: Up to 1A
  • Low-Dropout Regulator: Designed to work with a minimal difference between the input and output voltage
  • Protection Features: Overcurrent and thermal shutdown protection
  • Package: TO-263
