LM317EMPX/NOPB Texas Instruments LM317EMPX/NOPB Real Image LM317EMPX/NOPB label picture LM317EMPX/NOPB real image 2 LM317EMPX/NOPB label picture 2 LM317EMPX/NOPB real image1291 LM317EMPX/NOPB real image1292 LM317EMPX/NOPB real image1293 LM317EMPX/NOPB real image1294 LM317EMPX/NOPB Real Image1 LM317EMPX/NOPB Real Image2 LM317EMPX/NOPB Real Image3 LM317EMPX/NOPB Real Image4
Same model may have multiple batches, images only for reference.
LM317EMPX/NOPB Texas Instruments LM317EMPX/NOPB Real Image LM317EMPX/NOPB label picture LM317EMPX/NOPB real image 2 LM317EMPX/NOPB label picture 2 LM317EMPX/NOPB real image1291 LM317EMPX/NOPB real image1292 LM317EMPX/NOPB real image1293 LM317EMPX/NOPB real image1294 LM317EMPX/NOPB Real Image1 LM317EMPX/NOPB Real Image2 LM317EMPX/NOPB Real Image3 LM317EMPX/NOPB Real Image4
LM317EMPX/NOPB Texas Instruments LM317EMPX/NOPB Real Image LM317EMPX/NOPB label picture LM317EMPX/NOPB real image 2 LM317EMPX/NOPB label picture 2 LM317EMPX/NOPB real image1291 LM317EMPX/NOPB real image1292 LM317EMPX/NOPB real image1293 LM317EMPX/NOPB real image1294 LM317EMPX/NOPB Real Image1 LM317EMPX/NOPB Real Image2 LM317EMPX/NOPB Real Image3 LM317EMPX/NOPB Real Image4
Same model may have multiple batches, images only for reference.

LM317EMPX/NOPB

Part No LM317EMPX/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR ADJ 1A SOT223-4
Datasheet
LM317EMPX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 37V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 37V
Output Current 1A
PSRR 80dB to 65dB (120Hz)
Control Protection Features Over Circuit, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 37 V
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 104914-LM317EMPX/NOPB
Family Name LM317
Introduction Date January 15, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM317EMPX/NOPB CAD Model

Description

The LM317EMPX/NOPB is a highly efficient, versatile, and adjustable voltage regulator from Texas Instruments, a renowned global semiconductor company.

  • Adjustable Output Voltage: 1.25 to 37 volts
  • Load Current: more than 1.5A
  • Output Voltage Precision: 1%
  • Type: three-terminal positive regulator
  • Reference Voltage Tolerance: 2% @ 25°C
  • Applications: local and on-card regulation, programmable output regulation, and precision current regulation
  • Features: built-in thermal overload protection and safe-area compensation
  • Package: compact, surface-mount (SOT-223)
  • Compliance: RoHS compliant and lead-free
  • NOPB: No Pb, meaning it does not contain lead (Pb)
