LM317LIPK Real Image LM317LIPK real image1307 LM317LIPK real image1308 LM317LIPK Real Image1 LM317LIPK Real Image2 LM317LIPK Real Image3 LM317LIPK Real Image4
Same model may have multiple batches, images only for reference.
LM317LIPK Real Image LM317LIPK real image1307 LM317LIPK real image1308 LM317LIPK Real Image1 LM317LIPK Real Image2 LM317LIPK Real Image3 LM317LIPK Real Image4
LM317LIPK Real Image LM317LIPK real image1307 LM317LIPK real image1308 LM317LIPK Real Image1 LM317LIPK Real Image2 LM317LIPK Real Image3 LM317LIPK Real Image4
Same model may have multiple batches, images only for reference.

LM317LIPK

Part No LM317LIPK
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description Standard Regulator Pos 1.2V to 32V 0.1A 4-Pin(3+Tab) SOT-89 T/R / IC REG LINEAR ADJ 0.1A SOT89-3
Datasheet
LM317LIPK Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 38V
Nominal Output Voltage (Min/Fixed) 1.2V
Maximum Output Voltage 32V
Output Current 100mA
PSRR 80dB to 65dB (120Hz)
Control Protection Features Over Circuit, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.2 V to 32 V
Mounting SMD (SMT)
Case / Package SOT-89-3
Win Source Part Number 114813-LM317LIPK
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Commercial, Medical, Computers & Computer Peripherals, Consumer Electronics
Family Name LM317L
Introduction Date February 01, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM317LIPK CAD Model

Description

The LM317LIPK from Texas Instruments is a versatile and highly efficient adjustable voltage regulator that offers output voltage range from 1.25V to 37V.

  • Output Voltage Range: 1.25V to 37V
  • Load Current: Over 100mA
  • Current Limiting: Internal
  • Thermal Shutdown: Yes
  • Safe-Area Compensation: Yes
  • Package: Plastic TO-92 package
  • Operating Temperature Range: -40°C to 125°C
