Introducing the LM336MX-2.5 Voltage Reference from Texas Instruments

The LM336MX-2.5 is a precision 2.5V voltage reference with guaranteed temperature stability over the entire operating temperature range. Manufactured by Texas Instruments, a leader in semiconductor solutions, this component is designed to offer a reliable reference for various applications, including precision power supplies, digital voltmeters, and other measurement devices.

Key Features

• Accurate Voltage Reference: The LM336MX-2.5 provides a precise 2.5V output, which is crucial for systems that require a stable reference voltage for accurate measurements.
• Temperature Stability: This device is characterized for operation from −40°C to +85°C, ensuring consistent performance across a wide range of environmental conditions.
• Adjustable Output: While the default output is set to 2.5V, it can be adjusted over a range from 1V to over 10V with the use of external resistors, providing flexibility for different circuit designs.
• Low Dynamic Impedance: The dynamic output impedance of the LM336MX-2.5 is low, which helps maintain voltage stability under varying load conditions.

Applications

• Analog-to-Digital and Digital-to-Analog Converters
• Portable Instruments
• Data Acquisition Systems
• Electronic Scales
• Medical Instruments
• Industrial Process Control Systems

Product Specifications

The LM336MX-2.5 comes in an SOIC-8 package, which is suitable for surface-mount technology (SMT) and is widely used in modern electronic circuits for its compact footprint. It requires minimal external components, which simplifies the design and reduces the overall bill of materials for the end product. Texas Instruments ensures that this voltage reference meets the highest quality and reliability standards, making it a trusted choice for engineers and designers across various industries.

Whether you're developing precision instrumentation or looking for a stable voltage reference for your circuit, the LM336MX-2.5 from Texas Instruments is an excellent choice that combines accuracy, reliability, and versatility.
