LM5022MMX/NOPB Real Image LM5022MMX/NOPB real image LM5022MMX/NOPB Real Image1 LM5022MMX/NOPB Real Image2
Same model may have multiple batches, images only for reference.
LM5022MMX/NOPB Real Image LM5022MMX/NOPB real image LM5022MMX/NOPB Real Image1 LM5022MMX/NOPB Real Image2
LM5022MMX/NOPB Real Image LM5022MMX/NOPB real image LM5022MMX/NOPB Real Image1 LM5022MMX/NOPB Real Image2
Same model may have multiple batches, images only for reference.

LM5022MMX/NOPB

Part No LM5022MMX/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BOOST/SEPIC 10MSOP
Datasheet
LM5022MMX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, SEPIC
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 7.5 V to 14 V
Frequency - Switching 200kHz to 990kHz
Duty Cycle (Max) 95%
Synchronous Rectifier No
Clock Sync Yes
Control Features Frequency Control, Soft Start
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 10-VSSOP
Win Source Part Number 019368-LM5022MMX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LM5022MMX/NOPB CAD Model

Description

The LM5022MMX/NOPB is an advanced, high voltage pulse width modulation (PWM) controller developed by Texas Instruments, a leading global semiconductor company.

  • Input Voltage: 3V to 105V
  • Package: 10-pin VSSOP
  • Control: Current mode
  • Features: High voltage start-up regulator, low shutdown current
  • Protection: Under-voltage lockout, over-voltage protection, thermal shutdown
  • Features: Adjustable switching frequency, soft-start feature
