LM78M05CDT Real Image LM78M05CDT real image1688 LM78M05CDT Real Image1 LM78M05CDT Real Image2
Same model may have multiple batches, images only for reference.
LM78M05CDT Real Image LM78M05CDT real image1688 LM78M05CDT Real Image1 LM78M05CDT Real Image2
LM78M05CDT Real Image LM78M05CDT real image1688 LM78M05CDT Real Image1 LM78M05CDT Real Image2
Same model may have multiple batches, images only for reference.

LM78M05CDT

Part No LM78M05CDT
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.5A TO252-3
Datasheet
LM78M05CDT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Output Current 500mA
Operating Supply Current 3mA
PSRR 78dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 093102-LM78M05CDT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LM78M05CDT CAD Model

Description

The LM78M05CDT is a high-quality, three-terminal positive voltage regulator product from Texas Instruments, a world-renowned leader in the semiconductor industry. This device is designed to deliver a fixed output voltage of 5V with an output current of up to 500mA. It is specifically designed to cater to a wide variety of applications that require a regulated supply, making it an excellent choice for a diverse range of electronic devices and systems.

  • Input Voltage Range: 7.2V to 20V
  • Output Voltage: 5V
  • Output Current: Up to 500mA
  • Package: TO-252 (DPAK)
  • Features: Robust thermal overload protection, safe-area compensation, and RoHS compliance
