The LMV431AIMF/NOPB is a precision low-voltage adjustable shunt regulator from Texas Instruments (TI), designed with the purpose of offering a flexible solution for voltage regulation in a wide array of electronic applications. This particular model is part of the LMV431 series, well-known for their stability, accuracy, and ease of use.

Key Features

• Adjustable Output Voltage: The LMV431AIMF/NOPB offers an adjustable output voltage range from 1.24V to 30V, providing versatility for various design requirements.
• Low Minimum Operating Current: This device operates with a minimal current of 80µA, which is advantageous for power-sensitive applications.
• High Precision: With a typical temperature stability of only 50ppm/°C, the LMV431AIMF/NOPB ensures a consistent performance over a wide temperature range.
• Low Output Noise: It features a low output noise characteristic, making it suitable for noise-sensitive electronic systems.
• Small Form Factor: Housed in a SOT-23 package, the LMV431AIMF/NOPB is compact and suitable for space-constrained applications.

Applications

The LMV431AIMF/NOPB is highly versatile and can be utilized in a variety of applications, including but not limited to:

• Adjustable power supplies
• Battery chargers
• Switching power supply systems
• Motor control circuits
• Automotive electronics

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and the LMV431AIMF/NOPB is no exception. It is designed to meet the rigorous standards of the industry, ensuring high reliability and performance. The NOPB designation indicates that the product is lead-free, RoHS compliant, and designed for environmentally conscious applications.

Technical Specifications

Package: SOT-23<br> Output Voltage Range: 1.24V to 30V<br> Minimum Operating Current: 80µA<br> Temperature Stability: 50ppm/°C typical<br> Regulation: Excellent line and load regulation<br>

For engineers and designers looking for a reliable, adjustable shunt regulator, the LMV431AIMF/NOPB is an excellent choice that combines flexibility, precision, and compactness to meet a wide range of design challenges.
