NE556D Texas Instruments NE556D Real Image NE556D real image
Same model may have multiple batches, images only for reference.
NE556D Texas Instruments NE556D Real Image NE556D real image
NE556D Texas Instruments NE556D Real Image NE556D real image
Same model may have multiple batches, images only for reference.

NE556D

Part No NE556D
Manufacturer Texas Instruments
Catalog Clock/Timing - Programmable Timers and Oscillators
Description IC OSC TIMER DUAL 100KHZ 14SOIC
Datasheet
NE556D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type 555 Type, Timer/Oscillator (Dual)
Frequency 100kHz
Supply Voltage - Operating 4.5 V to 16 V
Operating Supply Current 20mA
Temperature Range - Operating 0°C to 70°C
Case / Package 14-SOIC
Mounting Surface Mount
Win Source Part Number 081967-NE556D
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Consumer Electronics, Industrial, Automotive
Ultra Librarian 3D Model Ultra Librarian NE556D CAD Model

Description

The NE556D from Texas Instruments is a highly versatile and reliable dual precision timer that is specifically designed to produce accurate time delays or oscillation.

  • Device Type: Dual Precision Timer
  • Manufacturer: Texas Instruments
  • Operating Modes: Astable and Monostable
  • Package: 14-pin package
  • Voltage Range: 4.5 to 16 volts
  • Output Current: 200mA
  • Temperature Stability: 50 parts per million (ppm) per degree Celsius change in temperature
  • Standards Compliance: RoHS and Green standards
