The OPA2336E, produced by Texas Instruments, is a high-precision operational amplifier that offers a perfect blend of speed and power efficiency. This operational amplifier is part of the OPAx336 series, which are CMOS operational amplifiers optimized for very low voltage, single-supply applications.
Operating on a power supply range of 2.1V to 5.5V, the OPA2336E is ideal for battery-powered instruments and portable devices due to its low power consumption. With a quiescent current of just 17µA, this op-amp is designed to maintain its performance while minimizing impact on battery life, making it a go-to choice for energy-sensitive applications.
The OPA2336E boasts a bandwidth of 1MHz and a slew rate of 0.4V/µs, which allows for a good balance between speed and power efficiency. Its precision is highlighted by a low offset voltage of 150µV and a low noise density of 19nV/√Hz, ensuring high accuracy in signal amplification and conditioning tasks.
This operational amplifier also features Rail-to-Rail input/output, which provides the maximum possible dynamic range at the output. This is especially useful in single-supply applications where the full supply range is often utilized. Additionally, the input common-mode voltage range includes ground, and the output can swing within 10mV of the rails, further enhancing its versatility in single-supply operations.
The OPA2336E comes in a variety of packages, including the space-saving SC70-5 and SOT23-5, which are suitable for space-constrained applications. Its robust design ensures performance is maintained over the extended industrial temperature range of -40°C to +125°C, making it reliable in diverse operating conditions.
With its combination of low power consumption, high precision, and Rail-to-Rail performance, the OPA2336E from Texas Instruments is an excellent choice for designers looking to optimize their applications in terms of power efficiency and operational excellence.
