The PCA9306IDCURQ1 is a robust, high-performance dual bidirectional I2C-bus and SMBus voltage-level shifter engineered by Texas Instruments. It is specifically designed to provide a seamless interface between devices operating at different voltage levels, making it an essential component for multi-voltage systems. The PCA9306IDCURQ1 allows for the direct connection of I2C-bus or SMBus devices with different voltage levels, thereby simplifying the design of complex multi-voltage digital systems.

Key Features:

• Voltage Level Translation: The PCA9306IDCURQ1 is capable of translating voltages between 1.8V and 5.5V, which allows for communication between devices that operate at these differing voltage levels.
• Bidirectional Communication: This device supports bidirectional communication on the I2C-bus and SMBus, enabling two-way data transfer without the need for a direction pin.
• Low Standby Current: It is designed for minimal power consumption with a low standby current, making it suitable for battery-powered and power-sensitive applications.
• High-Speed Operation: The PCA9306IDCURQ1 supports fast-mode I2C-bus devices and SMBus devices, allowing for high-speed data transfer up to 1 Mbps.
• No Direction Control: The device's design eliminates the need for direction control, simplifying the application circuit.
• Robust ESD Protection: It includes electrostatic discharge (ESD) protection exceeding JESD 22, ensuring durability and reliability in harsh environments.
• Automotive Qualification: The PCA9306IDCURQ1 is qualified for automotive applications, meeting the stringent requirements of the automotive industry for reliability and performance.

Applications:

The versatility of the PCA9306IDCURQ1 makes it suitable for a wide range of applications, especially where interfacing between different voltage domains is required. Common applications include automotive networks, cell phones, and personal electronics, as well as industrial and medical equipment that require multi-voltage I2C-bus or SMBus communications.

With its compact design, the PCA9306IDCURQ1 is available in a small 8-pin VSSOP package, providing a space-saving solution for PCB layouts. Its operational temperature range of -40°C to +85°C ensures reliable performance across various environmental conditions.
