Overview of SN74ACT3641-30PQ

The SN74ACT3641-30PQ is a high-performance, CMOS octal bus transceiver and register designed by the renowned semiconductor manufacturer, Texas Instruments. This integrated circuit is engineered to provide bidirectional communication between data buses while offering the flexibility of latch storage for the A port. The device is a part of the 74ACT series, known for its high-speed operation and compatibility with TTL (Transistor-Transistor Logic) levels.

Key Features

• Logic Family: The device belongs to the ACT family, ensuring fast switching speeds and high noise immunity characterized by CMOS technology.
• Bus Transceiver Type: It is an octal bus transceiver with 3-state outputs, which allows for bidirectional data flow with the ability to disconnect from the bus for multiplexing or when inactive.
• Number of Pins: The SN74ACT3641-30PQ comes in a 64-pin plastic QFP (Quad Flat Package), which is suitable for surface-mount technology (SMT).
• Operating Voltage: This device operates at a nominal supply voltage of 5V, which is typical for logic circuits compatible with TTL levels.
• Speed: It boasts a fast propagation delay, which is essential for high-speed data transmission and processing applications.
• Temperature Range: The SN74ACT3641-30PQ is designed to operate over the industrial temperature range, ensuring reliability in various environments.

Applications

Due to its high-speed and robust performance, the SN74ACT3641-30PQ is suitable for a variety of applications, including:

• Communication systems
• Data bus transceivers for microprocessor systems
• Memory switching operations
• Peripheral drivers

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the SN74ACT3641-30PQ is no exception. It is fabricated using state-of-the-art manufacturing processes, ensuring high reliability and performance consistency. This product is RoHS compliant, reflecting Texas Instruments' dedication to environmental responsibility.

The SN74ACT3641-30PQ by Texas Instruments is an excellent choice for designers looking for a high-speed, reliable octal bus transceiver and register for their digital systems. With its robust feature set and proven performance, this product is set to meet the demands of modern electronic applications.
