The SN74ACT3651-30PQ from Texas Instruments is a high-performance, CMOS logic integrated circuit designed to cater to a wide range of digital applications. This particular IC is part of the 74ACT series, which is well-known for its high-speed operation and compatibility with TTL levels.

Key Features:

• Logic Type: 8-bit Universal Bus Transceiver with 3-state outputs
• Package: The device is housed in a 24-pin plastic QFP (Quad Flat Package) that provides a compact footprint and reliable connectivity.
• Operating Voltage: Designed to operate with a nominal supply voltage of 5V, making it suitable for interfacing with traditional 5V logic families.
• Speed: Features a typical propagation delay time of 6ns, providing high-speed data transfer capabilities.
• I/O Capacitance: The I/O pins have a capacitance of 10pF, which is conducive to maintaining signal integrity at high speeds.
• Drive Capability: The outputs can drive up to 24mA, allowing for direct driving of LEDs or other light loads without the need for additional buffer components.

Applications:

The SN74ACT3651-30PQ is versatile and can be used in a variety of digital systems, including:

• Data communication
• Address and data bus interfacing
• Memory interfacing
• Microprocessor or microcontroller extension

Quality and Reliability:

Texas Instruments is known for its commitment to quality, and the SN74ACT3651-30PQ is no exception. It is designed to meet or exceed the stringent requirements of the industrial and commercial markets. The device is also RoHS compliant, ensuring that it meets current environmental standards for hazardous substances.

Support and Resources:

For additional information, such as detailed specifications, application notes, and design resources, customers can visit the Texas Instruments website. Technical support and community forums are also available to assist with any design challenges or questions regarding the SN74ACT3651-30PQ.
