SN74HCT00DR Real Image SN74HCT00DR real image6007
Same model may have multiple batches, images only for reference.
SN74HCT00DR Real Image SN74HCT00DR real image6007
SN74HCT00DR Real Image SN74HCT00DR real image6007
Same model may have multiple batches, images only for reference.

SN74HCT00DR

Part No SN74HCT00DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description NAND Gate 4-Element 2-IN CMOS 14-Pin SOIC T/R / IC GATE NAND 4CH 2-INP 14-SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 4mA, 4mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 18ns @ 5.5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006925-SN74HCT00DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SN74HCT00
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia, Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian SN74HCT00DR CAD Model

Description

The SN74HCT00DR is a high-performance, integrated circuit product manufactured by Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Function: quadruple 2-input positive-NAND gate device
  • Operating Voltage Range: 4.5V to 5.5V
  • Typical Propagation Delay Time: 10ns
  • Package: SOIC-14 package
  • Operating Temperature Range: -40°C to 85°C
  • Noise Immunity: typically 1.5V
