TLV272CDR

Part No TLV272CDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 3MHZ RRO 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 2.6 V/μs
Gain Bandwidth Product (GBP) 3MHz
Current - Input Bias 1pA
Voltage - Input Offset 500μV
Operating Supply Current 625μA
Channel Output Current 13mA
Supply Voltage - Operating 2.7 V to 16 V, ±1.35 V to 8 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 032976-TLV272CDR
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian TLV272CDR CAD Model

Description

The Texas Instruments TLV272CDR is a high-performance, dual operational amplifier (op-amp) that is designed to meet a wide array of application requirements. This versatile component is part of the TLV272 family that offers low-voltage operation and rail-to-rail output swings, both in single and dual supply configurations. The TLV272CDR is well-suited for battery-powered applications due to its low power consumption and wide operating voltage range.

Key Features

  • Low Power Consumption: The TLV272CDR is optimized for low power operations, making it ideal for portable and battery-operated devices. It ensures efficient energy usage, thus extending the battery life of the application it is used in.
  • Rail-to-Rail Output: This op-amp provides a rail-to-rail output which allows the output signal to swing very close to the supply rails, maximizing the dynamic range in various applications.
  • Wide Supply Voltage Range: With an operational range from 2.7V to 16V, the TLV272CDR can be used in systems that have varying supply voltages, offering great design flexibility.
  • High Output Drive Capability: It is capable of delivering a high current to drive capacitive loads, which is beneficial for applications requiring high power handling.
  • Stable Operation: The TLV272CDR is designed to be stable for capacitive loads as high as 10 nF, ensuring reliable performance across different use cases.

Applications

The TLV272CDR's versatility allows it to be utilized in a diverse range of applications, including:

  • Audio Processing
  • Sensor Signal Conditioning
  • Active Filters
  • Portable Electronic Devices
  • Analog to Digital Converters (ADC) Interface
  • Battery Management Systems

Package and Quality

The TLV272CDR comes in a small-outline integrated circuit (SOIC) package, which is well-suited for space-constrained applications. It is also available in other package options to cater to different design requirements. Texas Instruments ensures high-quality and reliability for the TLV272CDR, making it a trusted choice for engineers and designers looking for a robust operational amplifier for their electronic designs.
