TPS2065DBVT

Part No TPS2065DBVT
Manufacturer Texas Instruments
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC 1.5A PWR DIST SWITCH SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 2.7 V to 5.5 V
Supply Voltage - Operating Not Required
Current - Output (Max) 1A
Rds On (Typ) 70 mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package SOT-23-5
Win Source Part Number 033642-TPS2065DBVT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Motor Drive & Control
Ultra Librarian 3D Model Ultra Librarian TPS2065DBVT CAD Model

Description

Product Overview: Texas Instruments TPS2065DBVT

The TPS2065DBVT from Texas Instruments is a state-of-the-art single-channel, current-limited, power distribution switch designed for USB and other applications. It is a part of TI's extensive power management portfolio, which is renowned for its reliability and performance.

Key Features

  • Current Limiting: The device offers a 1A continuous current limit, which helps protect the host device from overcurrent conditions. This feature is particularly important for USB applications, where excessive current draw by a peripheral can cause damage to the USB port or the entire system.
  • Thermal Shutdown: With built-in thermal shutdown protection, the TPS2065DBVT automatically turns off if it gets too hot, thereby safeguarding the system from thermal damage.
  • Fast Transient Response: The device is designed to handle fast transients, which ensures stable operation even with quickly changing loads.
  • Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off if the input voltage is too low, preventing erratic operation of the connected device.

Applications

  • USB hubs and peripherals
  • Hot-swap supplies
  • Power management for portable devices
  • Overcurrent protection for various consumer electronics

Technical Specifications

  • Package: The TPS2065DBVT comes in a compact SOT-23-6 package, which is ideal for space-constrained applications.
  • Input Voltage Range: It operates over an input voltage range of 2.7V to 5.5V, accommodating a variety of power sources.
  • Switch On-Resistance: The low on-resistance of the internal switch (typically 105 mΩ) minimizes voltage drop and power dissipation.

The TPS2065DBVT is not only robust but also offers a high degree of functionality and ease of use. It is an excellent choice for designers looking for a power distribution solution that can provide both protection and efficiency. With the support of Texas Instruments' quality and technical expertise, this product stands out as a reliable component in any power management system.

Ordering and Packaging

This product is available in tape and reel packaging, facilitating easy integration into automated manufacturing processes. For detailed ordering and shipping information, please refer to the official Texas Instruments website or contact an authorized distributor.
