The TPS60150DRV from Texas Instruments is a high-performance, regulated charge pump that generates a 5V output from a 2.7V to 5.5V input. It is designed to deliver a fixed output voltage with high efficiency, which makes it an ideal power solution for portable devices that require a consistent 5V supply.

Key Features

• Input Voltage Range: The device supports an input voltage range of 2.7V to 5.5V, accommodating a wide variety of power sources, including single-cell lithium-ion batteries.
• High Efficiency: The TPS60150DRV utilizes a low-noise regulated charge pump to achieve high power conversion efficiency, which is crucial for battery-powered applications.
• Output Voltage: It provides a stable 5V output, which is essential for devices that require a consistent supply for optimal operation.
• Output Current: Capable of delivering up to 120mA of continuous output current, the device can power a range of low-power peripherals and ICs.
• Thermal Shutdown: The integrated thermal shutdown feature ensures the device operates within safe temperature ranges, enhancing system reliability.
• Small Package Size: Supplied in a compact DRV package, the TPS60150DRV is optimized for space-constrained applications.
• Low Ripple: The charge pump design minimizes output voltage ripple, providing a clean power supply for noise-sensitive circuits.

Applications

The TPS60150DRV is versatile and can be used in a variety of applications, including but not limited to:

• Handheld Devices
• Portable Media Players
• Wireless Headsets
• Battery-Powered Equipment
• USB-Powered Gadgets

With its combination of efficiency, reliability, and compact size, the TPS60150DRV from Texas Instruments is an excellent choice for designers looking to implement a stable 5V power supply in their next portable or battery-powered project.
