TPS76350DBVRG4

Part No TPS76350DBVRG4
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.15A SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 10V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 5.2V @ 150mA
Output Current 150mA
Operating Supply Current 100μA to 140μA
PSRR 60dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.18V @ 150mA
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 055911-TPS76350DBVRG4
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian TPS76350DBVRG4 CAD Model

Description

Product Overview: TPS76350DBVRG4 from Texas Instruments

The TPS76350DBVRG4 is a low-dropout (LDO) voltage regulator designed and manufactured by the renowned leader in semiconductor technology, Texas Instruments. This high-performance component is engineered to deliver a fixed output voltage of 5.0V with an impressive accuracy of 2%, making it a reliable choice for precision applications.

Key Features

  • Output Voltage: The TPS76350DBVRG4 provides a stable 5.0V output, suitable for a wide range of electronic devices.
  • Low Dropout Voltage: With a low dropout voltage, this LDO regulator maintains its output regulation with minimal input-to-output voltage difference, enhancing efficiency in operation.
  • High Output Accuracy: The output voltage accuracy is maintained within 2%, ensuring consistent performance and reliability for sensitive circuits.
  • Current Capacity: It can supply up to 150mA of output current, catering to moderate power requirements.
  • Power Consumption: The quiescent current is low, making it an energy-efficient solution for battery-powered applications.
  • Thermal Shutdown and Overcurrent Protection: Built-in safety features protect the device against excessive temperature and current, enhancing the longevity of the product and the safety of the application.
  • Small Package Size: The TPS76350DBVRG4 comes in a compact SOT-23-5 package, which is ideal for space-constrained applications.

Applications

The TPS76350DBVRG4 is versatile and can be used in a variety of applications, including:

  • Battery-powered devices
  • Portable and handheld equipment
  • Microcontroller power supplies
  • Reference voltage sources
  • Consumer electronics

Quality and Reliability

As with all Texas Instruments products, the TPS76350DBVRG4 is designed to meet high standards of quality and reliability. It is a testament to Texas Instruments' commitment to providing components that ensure long-term performance in a range of environmental conditions.
