Overview of Texas Instruments TPS76933DBVT

The Texas Instruments TPS76933DBVT is a highly efficient, low-dropout (LDO) voltage regulator, offering a stable 3.3V output with an input voltage range from 2.7V to 10V. This compact regulator is part of the TPS769xx family and comes in a SOT-23-5 package, designed to support a wide range of applications including portable electronics, microcontrollers, and analog devices.

Key Features

• Stable Output: The TPS76933DBVT provides a fixed output voltage of 3.3V, which is essential for consistent performance in electronic circuits.
• Low Dropout: With a low dropout voltage, this LDO regulator can maintain a stable output even when the input voltage is very close to the output voltage, making it ideal for battery-operated devices.
• High Accuracy: Output voltage accuracy is within ±2%, ensuring reliable and consistent power for sensitive components.
• Low Quiescent Current: The device features a low quiescent current of 17 µA (typical), extending battery life in portable applications.
• Thermal Shutdown and Overcurrent Protection: Built-in safety features protect the device and the application from damage due to excessive heat or current.
• Small Footprint: The SOT-23-5 package is small and ideal for space-constrained applications.

Applications

The TPS76933DBVT is suitable for a variety of applications, including but not limited to:

• Portable and battery-powered devices
• Microcontroller power supply
• Power management for DSPs and other processors
• Analog circuit supply
• Reference voltage supply

Technical Specifications

The TPS76933DBVT from Texas Instruments is a reliable and versatile voltage regulator that offers the precision and durability required for modern electronic applications.
