TPS78401DBVR

Part No TPS78401DBVR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LIN POS ADJ 300MA SOT23-5
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Features Linear Voltage Regulator IC Positive Adjustable Output 300mA SOT-23-5
Manufacturer Texas Instruments
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package SC-74A, SOT-753
Case / Package SOT-23-5
Family Name TPS78401
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-TPS78401DBVRCT, 296-TPS78401DBVRTR, 296-TPS78401DBVRDKR
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 937382-TPS78401DBVR
Ultra Librarian 3D Model Ultra Librarian TPS78401DBVR CAD Model

Description

Product Overview: TPS78401DBVR from Texas Instruments

The TPS78401DBVR is a highly efficient, low-dropout linear voltage regulator designed and manufactured by Texas Instruments, a leader in the semiconductor industry. This compact component is engineered to provide a stable and reliable power supply for a wide range of applications, including portable electronics, wireless communication devices, and various other consumer and industrial products.

Key Features

  • Output Voltage: The TPS78401DBVR offers a fixed output voltage of 1.8V, which is ideal for powering low-voltage digital circuits and ensuring consistent performance.
  • High Accuracy: With an impressive output voltage accuracy of ±1%, this regulator ensures precise voltage delivery, vital for sensitive electronic equipment.
  • Low Dropout: The low dropout voltage of the TPS78401DBVR allows it to continue regulating the output voltage effectively even when the input-to-output voltage differential is minimal, making it suitable for battery-operated devices.
  • Current Capacity: Capable of delivering up to 150mA of continuous output current, this regulator can support a range of low-power applications.
  • Thermal Shutdown: To protect against overheating, the device includes a thermal shutdown feature that disables the output when the junction temperature exceeds the threshold.
  • Overcurrent Protection: The built-in current limit function helps prevent damage to the regulator and the downstream circuitry in the event of an output overload.

Package and Design

The TPS78401DBVR comes in a compact SOT-23-5 package, which is highly valued for its small footprint and low profile, making it an excellent choice for space-constrained applications. The device's pinout is designed for optimal board layout, facilitating easy integration into a variety of circuit designs.

Applications

Due to its versatile features, the TPS78401DBVR is suitable for a multitude of applications, including but not limited to:

  • Mobile phones and PDAs
  • GPS devices
  • Portable media players
  • Wireless LAN and Bluetooth® modules
  • Healthcare devices like portable medical equipment

In summary, the TPS78401DBVR from Texas Instruments is a robust, high-performance voltage regulator that offers stability and reliability for a variety of electronic devices where power efficiency and space savings are critical.
