Introducing the TPS799285YZUR Voltage Regulator from Texas Instruments

The TPS799285YZUR is a state-of-the-art low-dropout (LDO) linear voltage regulator that offers the perfect balance between high performance and energy efficiency. Manufactured by Texas Instruments, a leader in semiconductor solutions, this regulator is designed to cater to a wide array of applications, from battery-powered devices to sensitive RF components.

Key Features

• High Accuracy: The TPS799285YZUR provides an impressive output voltage accuracy of 2%, ensuring reliable performance for precision-dependent applications.
• Low Dropout: With a low dropout voltage of just 40mV at a 200mA load, it allows operations close to the supply voltage, maximizing battery life in portable applications.
• Low Quiescent Current: The device boasts an ultra-low quiescent current of 40µA (typical), making it ideal for power-sensitive systems.
• Thermal Shutdown and Overcurrent Protection: Built-in safety features protect the device and the system from excessive temperatures and currents.
• Wide Operating Range: The TPS799285YZUR operates over a broad input voltage range from 2.7V to 6.5V, accommodating a variety of power sources.
• Adjustable Output: The output voltage is adjustable from 1.2V to 6.5V, providing flexibility for different design requirements.

Applications

The versatility of the TPS799285YZUR allows it to be used in multiple applications including:

• Portable and battery-powered devices
• Wireless LAN and Bluetooth® systems
• Handheld medical equipment
• RF power supplies
• High-efficiency post-regulation applications

Package and Availability

The TPS799285YZUR comes in a highly compact, 5-pin SOT-23 package, which is ideal for space-constrained applications. Its small footprint does not compromise its performance or reliability, making it an excellent choice for designers looking to minimize board space while maintaining high standards of power regulation.

With Texas Instruments' commitment to quality and long-term reliability, the TPS799285YZUR is a smart choice for engineers and designers seeking an LDO that does not compromise on efficiency or performance. Its combination of features ensures that it can meet the needs of the most demanding applications, while its small size makes it perfect for the latest generation of portable and miniaturized electronics.
