TPS7A8300RGWR Voltage Regulator by Texas Instruments

The TPS7A8300RGWR from Texas Instruments is a highly efficient, low-noise, fast-transient response, low-dropout linear regulator capable of sourcing a 2A load with excellent line and load regulation. It is designed to meet the rigorous power and precision requirements of sensitive RF and analog circuitry in high-performance applications.

Key Features

• Output Voltage Range: This regulator offers an adjustable output voltage range from 0.8V to 3.95V, allowing for versatile applications across various electronic devices.
• High Accuracy: The output voltage is accurate to within 1% over the full temperature range, ensuring reliable performance in critical applications.
• Low Dropout: The low dropout voltage minimizes power loss and improves efficiency, making it ideal for battery-powered devices.
• Low Noise: With an ultra-low output noise of 4µVRMS, the TPS7A8300RGWR is perfect for powering noise-sensitive circuits such as precision amplifiers, ADCs, DACs, and high-speed data converters.
• Fast Transient Response: The device's fast transient response helps maintain a stable output voltage despite rapid changes in load, which is crucial for high-speed digital ICs.

Applications

The TPS7A8300RGWR is widely used in a variety of applications, including:

• RF Power Amplifiers
• Medical Equipment
• Telecommunications Infrastructure
• High-Speed Analog and Digital Circuits
• Portable and Battery-Powered Equipment

Package and Reliability

The device is offered in a 20-pin VQFN package with a small footprint, providing a compact solution for space-constrained applications. It also features thermal shutdown and overcurrent protection, enhancing its reliability and longevity in the field.

Part Number Information

The Texas Instruments part number TPS7A8300RGWR refers to the specific model in the TPS7A83 series, available in tape and reel packaging for automated assembly processes.
