The TS3L4892RHHR is a high-performance, quad SPDT (single pole double throw) switch manufactured by Texas Instruments. This device is designed to operate from a single 3.3-V or 2.5-V power supply, making it highly versatile for a wide range of applications. The TS3L4892RHHR is part of Texas Instruments' extensive switch and multiplexer product line, renowned for its reliability and performance.

Key Features

• Wide Operating Range: The device functions optimally with a power supply range of 2.3 V to 3.6 V, accommodating various system requirements.
• Low Power Consumption: With its low on-state resistance (Ron), the TS3L4892RHHR ensures minimal power loss during operation, thereby enhancing overall energy efficiency.
• High Bandwidth: The switch offers a wide bandwidth, which facilitates the transmission of high-speed signals without significant attenuation.
• ESD Protection: Integrated ESD protection circuits safeguard the device against electrostatic discharges, enhancing its durability and lifespan.
• Break-Before-Make Feature: This ensures that signal integrity is maintained during switching by preventing simultaneous connections of multiple signal paths.

Applications

The TS3L4892RHHR is suitable for a variety of applications, including but not limited to:

• Data Communication Equipment
• Signal Routing and Multiplexing
• Audio and Video Switching
• Server and Network Infrastructure
• Telecommunication Systems

Product Specifications

Parameter Value Supply Voltage (V<sub>CC) 2.3 V to 3.6 V On-State Resistance (Ron) Typically 5 Ω Bandwidth High ESD Protection Yes Switch Configuration Quad SPDT

With its robust feature set, the TS3L4892RHHR from Texas Instruments represents an excellent choice for designers looking for a reliable switch that can handle both analog and digital signals with precision and efficiency.
