Product Overview: Texas Instruments TXS0102DCTT

The Texas Instruments TXS0102DCTT is a 2-bit bidirectional voltage-level translator designed for I2C-bus and other applications. This versatile device is part of Texas Instruments' TXS series and is specifically engineered to address the challenges of communicating between different voltage domains in a mixed-voltage digital system.

Key Features

• Voltage-Level Translation: The TXS0102DCTT allows for bidirectional voltage-level translation between high-voltage (5.5 V) and low-voltage (1.65 V) domains without the need for a direction pin.
• Compatibility: It is compatible with a wide range of applications, including I2C-bus, SMBus, PMBus, and other systems that require voltage-level translation.
• Auto-Direction Sensing: The device automatically senses and adjusts the direction of data flow, simplifying design and reducing system complexity.
• Low Standby Current: The low standby current consumption makes it suitable for battery-operated and power-sensitive applications.
• ESD Protection: Integrated electrostatic discharge (ESD) protection circuits shield the device from static electricity and other voltage spikes, ensuring robust performance and longevity.

Applications

The TXS0102DCTT is ideal for a range of applications that require reliable voltage-level translation, such as:

• Mobile Phones
• Tablets
• GPS Systems
• Data Communication Systems
• Embedded Systems

Technical Specifications

The device comes in a compact 8-pin SSOP package and operates over the industrial temperature range of -40°C to 85°C. It features a V<sub>CCA range of 1.65 V to 3.6 V and a V<sub>CCB range of 2.3 V to 5.5 V, making it suitable for interfacing between low-voltage and higher-voltage components. Its low on-state resistance ensures minimal signal distortion during level translation.

In conclusion, the Texas Instruments TXS0102DCTT is a high-performance, versatile solution for systems that require voltage-level translation between different logic levels. Its automatic bidirectional functionality, coupled with robust ESD protection, makes it a reliable and essential component for modern electronic designs.
