K15A60U Real Image K15A60U real image
Same model may have multiple batches, images only for reference.
K15A60U Real Image K15A60U real image
K15A60U Real Image K15A60U real image
Same model may have multiple batches, images only for reference.

K15A60U

Part No K15A60U
Manufacturer Toshiba Semiconductor and Storage
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 600V 15A TO-220SIS
Datasheet
K15A60U Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 600V
Continuous Drain Current at 25°C 15A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 1mA
Max Gate Charge 17nC @ 10V
Max Input Capacitance 950pF @ 10V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 40W (Tc)
Maximum Rds On at Id,Vgs 300 mOhm @ 7.5A, 10V
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-220SIS
Dimension TO-220-3 Full Pack
Win Source Part Number 205793-K15A60U
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian K15A60U CAD Model

Description

The K15A60U is a MOSFET semiconductor product manufactured by Toshiba Semiconductor and Storage. It is a high popular product and has a balanced supply and demand status. It is a discrete semiconductor product with a TO-220SIS package and N-Channel polarity.

  • Maximum Drain-Source Breakdown Voltage: 600V
  • Continuous Drain Current @ 25°C: 15A
  • RoHS compliant: and is known for its high performance and reliability, making it ideal for use in a variety of electronic devices.
