TLP109 Toshiba Semiconductor and Storage TLP109 real image
Same model may have multiple batches, images only for reference.
TLP109 Toshiba Semiconductor and Storage TLP109 real image
TLP109 Toshiba Semiconductor and Storage TLP109 real image
Same model may have multiple batches, images only for reference.

TLP109

Part No TLP109
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 5-Pin SO Magazine / OPTOISO 3.75KV TRANS 6-SO 5 LEAD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 20% @ 16mA
Switching Turn-On and Turn-Off Time 800ns, 800ns (Max)
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.64V
Continuous forward current- Max 20mA
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 6-SO, 5 Lead
Win Source Part Number 101948-TLP109
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TLP109
Introduction Date October 01, 2008
ECCN EAR99
Country of Origin Japan, Thailand
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TLP109 CAD Model

Description

The Toshiba Semiconductor and Storage TLP109 is an isolator with a transistor output type.

  • Output Type: Transistor
  • Forward Voltage: 1.64V
  • Input Type: DC
  • Number of Channels: 1
  • Isolation Voltage: 3750Vrms
  • Family Name: TLP109
  • Category: Isolators
  • Temperature Range: -55°C to 125°C
  • Case/Package: 6-SO, 5 Lead
  • Minimum DC Current Transfer Ratio: 20% @ 16mA
  • Switching Turn-On Time: 800ns (Max)
  • Switching Turn-Off Time: 800ns (Max)
  • Maximum Output Voltage: 20V
  • Channel Output Current: 8mA
  • Continuous Forward Current - Max: 20mA
  • Supply and Demand Status: Sufficient
  • Win Source Part Number: 101948-TLP109
