TLP241A(TP1,F Toshiba Semiconductor and Storage TLP241A(TP1,F real image TLP241A(TP1,F label picture
Same model may have multiple batches, images only for reference.
TLP241A(TP1,F Toshiba Semiconductor and Storage TLP241A(TP1,F real image TLP241A(TP1,F label picture
TLP241A(TP1,F Toshiba Semiconductor and Storage TLP241A(TP1,F real image TLP241A(TP1,F label picture
Same model may have multiple batches, images only for reference.

TLP241A(TP1,F

Part No TLP241A(TP1,F
Manufacturer Toshiba Semiconductor and Storage
Catalog Solid State Relays
Description PHOTORELAY SPST-NO 2A 40V / Solid State Relay 19.5mA 1.4V DC-IN AC/DC-OUT 4-Pin PDIP SMD Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Toshiba Semiconductor and Storage
Series TLP241A
Packaging Reel package
Circuit SPST-NO (1 Form A)
Output Type AC, DC
On-State Resistance (Maximum) 150 mOhm
Load Current 2A
Voltage - Input 1.27VDC
Voltage - Load 0 ~ 40 V
Mounting SMD
Termination Style Gull Wing
Package 4-SMD (0.300", 7.62mm)
Manufacturer Package 4-SMD
Relay Type Relay
Win Source Part Number 797046-TLP241A(TP1,F
Popularity Medium
Supply and Demand Status Limited
Family Name TLP241A(TP1,F
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TLP241A(TP1,F CAD Model

Description

The TLP241A relay by Toshiba Semiconductor and Storage is a 4-SMD (0.300", 7.62mm) package relay.

  • Circuit: SPST-NO (1 Form A)
  • Input Voltage: 1.27VDC
  • Output Type: AC, DC
  • Load Current: 2A
  • Voltage Range: 0 ~ 40 V
  • Series: TLP241A
  • Termination Style: Gull Wing
  • On-State Resistance (Maximum): 150 mOhm
  • Category: Relays
  • Country of Origin: Japan
  • Estimated EOL Date: 2026
  • Supply and Demand Status: Limited
