TLP293-4(GB,E real image17399 TLP293-4(GB,E Real Image1 TLP293-4(GB,E Real Image2 TLP293-4(GB,E Real Image3
Same model may have multiple batches, images only for reference.
TLP293-4(GB,E real image17399 TLP293-4(GB,E Real Image1 TLP293-4(GB,E Real Image2 TLP293-4(GB,E Real Image3
TLP293-4(GB,E real image17399 TLP293-4(GB,E Real Image1 TLP293-4(GB,E Real Image2 TLP293-4(GB,E Real Image3
Same model may have multiple batches, images only for reference.

TLP293-4(GB,E

Part No TLP293-4(GB,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS SO16 / Optoisolator Transistor Output 3750Vrms 4 Channel 16-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Optoisolators - Transistor, Photovoltaic Output
Mfr Toshiba Semiconductor and Storage
Package Tube
Number of Channels 4
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Min) 100% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Turn On / Turn Off Time (Typ) 3µs, 3µs
Rise / Fall Time (Typ) 2µs, 3µs
Input Type DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.25V
Current - DC Forward (If) (Max) 50 mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C ~ 125°C
Mounting SMD (SMT)
Package / Case 16-SOIC (0.179", 4.55mm Width)
Supplier Device Package 16-SO
Base Product Number TLP293
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Other Names TLP293-4(GBE,TLP293-4(GB,E(T
Standard Package 50
Win Source Part Number 970367-TLP293-4(GB,E
Ultra Librarian 3D Model Ultra Librarian TLP293-4(GB,E CAD Model

Description

The TLP293-4(GB,E) is an optoisolator with a photovoltaic output that is suitable for use in a variety of electronic applications.

  • Manufacturer: Toshiba Semiconductor and Storage
  • Packaging: Tube
  • Standard Package: 50
  • Mounting Technology: SMD (SMT)
  • Channels: 4
  • Voltage Isolation: 3750Vrms
  • Maximum Output Voltage: 80V
  • Vce Saturation: 300mV
  • Market Status: Open market
  • ECCN: EAR99
  • MSL Level: 1
  • HTSUS: 8541.49.8000
