TPHR8504PL,L1Q Toshiba Semiconductor and Storage TPHR8504PL,L1Q Real Image1 TPHR8504PL,L1Q Real Image2
Same model may have multiple batches, images only for reference.
TPHR8504PL,L1Q Toshiba Semiconductor and Storage TPHR8504PL,L1Q Real Image1 TPHR8504PL,L1Q Real Image2
TPHR8504PL,L1Q Toshiba Semiconductor and Storage TPHR8504PL,L1Q Real Image1 TPHR8504PL,L1Q Real Image2
Same model may have multiple batches, images only for reference.

TPHR8504PL,L1Q

Part No TPHR8504PL,L1Q
Manufacturer Toshiba Semiconductor and Storage
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 150A 8SOP / Trans MOSFET N-CH Si 40V 340A 8-Pin SOP Advance T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Toshiba Semiconductor and Storage
Series U-MOSIX-H
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 40V
Current - Continuous Drain (Id) @ 25°C 150A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2.4V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs 103nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 9600pF @ 20V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 1W (Ta), 170W (Tc)
Rds On (Maximum) @ Id, Vgs 0.85 mOhm @ 50A, 10V
Operating Temperature Range 175°C (TJ)
Mounting SMD
Manufacturer Package 8-SOP Advance (5x5)
Package 8-PowerVDFN
Win Source Part Number 797829-TPHR8504PL,L1Q
Popularity Medium
Supply and Demand Status Limited
Family Name TPHR8504PL
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian TPHR8504PL,L1Q CAD Model

Description

The TPHR8504PL N-Channel MOSFET is designed for use in high current applications. Toshiba Semiconductor and Storage

  • Continuous Drain Current @ 25°C: 150A
  • Rds On (Maximum): 0.85 mOhm @ 50A and 10V
  • Vgs(th) (Maximum): 2.4V @ 1mA
  • Gate Charge: 103nC @ 10V
  • Input Capacitance: 9600pF @ 20Vds
  • Power Dissipation (Maximum) (Ta): 1W
  • Power Dissipation (Maximum) (Tc): 170W
  • Package: 8-PowerVDFN
  • Mounting: SMD
  • Family Name: TPHR8504PL
  • ECCN: EAR99
  • Estimated EOL Date: 2030
