1N4148W-HE3-08 Real Image 1N4148W-HE3-08 real image24068 1N4148W-HE3-08 Real Image1 1N4148W-HE3-08 Real Image2
Same model may have multiple batches, images only for reference.
1N4148W-HE3-08 Real Image 1N4148W-HE3-08 real image24068 1N4148W-HE3-08 Real Image1 1N4148W-HE3-08 Real Image2
1N4148W-HE3-08 Real Image 1N4148W-HE3-08 real image24068 1N4148W-HE3-08 Real Image1 1N4148W-HE3-08 Real Image2
Same model may have multiple batches, images only for reference.

1N4148W-HE3-08

Part No 1N4148W-HE3-08
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 75V 150MA SOD123 / Diode 75 V 150mA Surface Mount SOD-123
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Vishay
Series Automotive, AEC-Q101
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 75 V
Current - Average Rectified (Io) 150mA
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 100 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 4 ns
Current - Reverse Leakage @ Vr 100 µA @ 100 V
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number 1N4148
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 850837-1N4148W-HE3-08
Ultra Librarian 3D Model Ultra Librarian 1N4148W-HE3-08 CAD Model

Description

The Vishay 1N4148W-HE3-08 is a standard diode from Vishay.

  • Voltage: 75 V
  • Average Rectified Current: 150 mA
  • Forward Voltage: 1.2 V @ 100 mA
  • Reverse Recovery Time: 4 ns
  • Package: SOD-123
  • Operating Temperature: -55°C to 150°C
  • Standard Package: 3,000 pcs
