IHLP5050FDER8R2M5A

Part No IHLP5050FDER8R2M5A
Manufacturer Vishay
Catalog Fixed Inductors
Description FIXED IND 8.2UH 13.2A 14.12 MOHM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Molded
Inductance 8.2 µH
Tolerance ±20%
Current Rating (Amps) 13.2 A
Current - Saturation (Isat) 7.6A
Shielding Shielded
DC Resistance (DCR) 14.12mOhm Max
Frequency - Self Resonant 10.3MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.522" L x 0.508" W (13.26mm x 12.90mm)
Height - Seated (Max) 0.252\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1532182-IHLP5050FDER8R2M5A
Ultra Librarian 3D Model Ultra Librarian IHLP5050FDER8R2M5A CAD Model
