IRFL9110TRPBF Real Image IRFL9110TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRFL9110TRPBF Real Image IRFL9110TRPBF Real Image
IRFL9110TRPBF Real Image IRFL9110TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRFL9110TRPBF

Part No IRFL9110TRPBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 100V 1.1A SOT223
Datasheet
IRFL9110TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 1.1A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 8.7nC @ 10V
Max Input Capacitance 200pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 2W (Ta), 3.1W (Tc)
Maximum Rds On at Id,Vgs 1.2 Ohm @ 660mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Dimension TO-261-4, TO-261AA
Win Source Part Number 016299-IRFL9110TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFL9110TRPBF CAD Model

Description

The Vishay IRFL9110TRPBF is a P-channel MOSFET with a drain-source breakdown voltage of 100V.

  • Maximum Gate-Source Voltage: ±20V
  • Maximum Rds On at Id,Vgs: 1.2 Ohm @ 660mA, 10V
  • Drive Voltage: 10V
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 8.7nC @ 10V
  • Maximum Input Capacitance: 200pF @ 25V
  • Continuous Drain Current: 1.1A (Tc) @ 25°C
  • Power Dissipation: 2W (Ta), 3.1W (Tc)
  • Package: SOT-223
  • Compliance: RoHS regulations
  • Popularity: high
