IRFP240PBF Real Image IRFP240PBF Real Image1 IRFP240PBF Real Image2 IRFP240PBF Real Image3
Same model may have multiple batches, images only for reference.
IRFP240PBF Real Image IRFP240PBF Real Image1 IRFP240PBF Real Image2 IRFP240PBF Real Image3
IRFP240PBF Real Image IRFP240PBF Real Image1 IRFP240PBF Real Image2 IRFP240PBF Real Image3
Same model may have multiple batches, images only for reference.

IRFP240PBF

Part No IRFP240PBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 20A TO-247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 70nC @ 10V
Max Input Capacitance 1300pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 150W (Tc)
Maximum Rds On at Id,Vgs 180 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247-3
Dimension TO-247-3
Win Source Part Number 017627-IRFP240PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRFP240
Introduction Date March 27, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian IRFP240PBF CAD Model

Description

The Vishay IRFP240PBF is an N-Channel MOSFET with a drain-source breakdown voltage of 200V and a continuous drain current at 25°C of 20A (Tc).

  • Drain-Source Breakdown Voltage: 200V
  • Continuous Drain Current at 25°C: 20A (Tc)
  • Maximum Rds On at Id,Vgs: 180 mOhm @ 12A, 10V
  • Maximum Gate-Source Voltage: ±20V
  • Family: IRFP240
  • Mounting Type: Through Hole
  • Case / Package: TO-247-3
  • Win Source Part Number: 017627-IRFP240PBF
