SI1563EDH-T1-E3

Name: SI1563EDH-T1-E3
Brand: Vishay
SKU: 320891
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

Part No	SI1563EDH-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N/P-CH 20V 1.13A/0.88A 6-Pin SC-70 T/R / MOSFET N/P-CH 20V 1.13A SC70-6
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Obsolete(EOL)
FET Type	N and P-Channel
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	20V
Continuous Drain Current at 25°C	1.13A, 880mA
Maximum Rds On at Id,Vgs	280 mOhm @ 1.13A, 4.5V
Gate-Source Threshold Voltage	1V @ 100μA
Max Gate Charge	1nC @ 4.5V
Maximum Power Dissipation	570mW
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SC-70-6 (SOT-363)
Win Source Part Number	135400-SI1563EDH-T1-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	Si1563EDH
Introduction Date	May 21, 2001
ECCN	EAR99
Country of Origin	China
Halogen Free	Not Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian SI1563EDH-T1-E3 CAD Model

Alternative Products

Description

Vishay's SI1563EDH-T1-E3 is a high-quality N and P-channel FET that is designed for use in a variety of electronic applications.

Gate Type: logic level
Maximum Power Dissipation: 570mW
Supply and Demand Status: limited
