Same model may have multiple batches, images only for reference.

SI2305DS-T1-E3

Name: SI2305DS-T1-E3
Brand: Vishay
SKU: 320999
Availability: InStock
Rating: 4.93 (195 reviews)

Get a Quote

Part No	SI2305DS-T1-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH 8V 3.5A 3-Pin SOT-23 T/R / MOSFET P-CH 8V 3.5A SOT23-3
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Cut Reel
Status	Obsolete(EOL)
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	8V
Continuous Drain Current at 25°C	3.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	1.8V, 4.5V
Gate-Source Threshold Voltage	800mV @ 250μA
Max Gate Charge	15nC @ 4.5V
Max Input Capacitance	1245pF @ 4V
Maximum Gate-Source Voltage	±8V
Power Dissipation (Max)	1.25W (Ta)
Maximum Rds On at Id,Vgs	52 mOhm @ 3.5A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	103786-SI2305DS-T1-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management, Portable Devices
Family Name	Si2305DS
Introduction Date	April 17, 2000
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian SI2305DS-T1-E3 CAD Model

Alternative Products

Description

Supply and Demand Status: Sufficient
Polarity: P-Channel
Power Dissipation: 1.25W (Ta)
Maximum Rds on @ Id,Vgs: 52 mOhm @ 3.5A, 4.5V
Product Status: Obsolete (EOL)
Application: Industrial, Power Management, and Portable Devices
Win Source Part Number: 103786-SI2305DS-T1-E3
