SI2312CDS-T1-GE3 Real Image SI2312CDS-T1-GE3 real image5394 SI2312CDS-T1-GE3 real image5395
Same model may have multiple batches, images only for reference.
SI2312CDS-T1-GE3 Real Image SI2312CDS-T1-GE3 real image5394 SI2312CDS-T1-GE3 real image5395
SI2312CDS-T1-GE3 Real Image SI2312CDS-T1-GE3 real image5394 SI2312CDS-T1-GE3 real image5395
Same model may have multiple batches, images only for reference.

SI2312CDS-T1-GE3

Part No SI2312CDS-T1-GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 20V 6A 3-Pin SOT-23 T/R / MOSFET N-CH 20V 6A SOT-23
Datasheet
SI2312CDS-T1-GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 6A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 1.8V, 4.5V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 18nC @ 5V
Max Input Capacitance 865pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 1.25W (Ta), 2.1W (Tc)
Maximum Rds On at Id,Vgs 31.8 mOhm @ 5A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3 (TO-236)
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 028379-SI2312CDS-T1-GE3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Portable Devices
Family Name Si2312CDS
Introduction Date March 23, 2010
ECCN EAR99
Country of Origin China, Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SI2312CDS-T1-GE3 CAD Model

Description

This electronic component is manufactured by Vishay and is highly popular in the market.

  • Application: Power Management and Portable Devices
  • Technology: MOSFET
  • Polarity: N-Channel
  • Maximum Rds On @ Id, Vgs: 31.8 mOhm @ 5A, 4.5V
  • Gate-Source Threshold Voltage: 1V @ 250μA
  • Maximum Gate-Source Voltage: ±8V
  • Maximum Input Capacitance: 865pF @ 10V
  • Maximum Gate Charge: 18nC @ 5V
  • Continuous Drain Current: 6A (Tc) @ 25°C
  • Drain-Source Breakdown Voltage: 20V
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Mounting: SMD (SMT)
  • Case/Package: SOT-23-3 (TO-236)
  • Halogen-Free Compliant: Yes
