SI2337DS-T1-GE3

Name: SI2337DS-T1-GE3
Brand: Vishay
SKU: 321067
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2337DS-T1-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET P-CH 80V 2.2A 3-Pin SOT-23 T/R / MOSFET P-CH 80V 2.2A SOT23-3
Datasheet	SI2337DS-T1-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	80V
Continuous Drain Current at 25°C	2.2A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	17nC @ 10V
Max Input Capacitance	500pF @ 40V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	760mW (Ta), 2.5W (Tc)
Maximum Rds On at Id,Vgs	270 mOhm @ 1.2A, 10V
Temperature Range - Operating	-50°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	064398-SI2337DS-T1-GE3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Industrial, Power Management
Family Name	Si2337DS
Introduction Date	December 02, 2005
ECCN	EAR99
Country of Origin	China, Taiwan
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian SI2337DS-T1-GE3 CAD Model

Alternative Products

Description

The Vishay SI2337DS-T1-GE3 is a P-channel MOSFET with a maximum power dissipation of 760mW (Ta), 2.5W (Tc).

Family Name: Si2337DS
Case/Package: SOT-23-3 (TO-236)
Drain-Source Breakdown Voltage: 80V
Continuous Drain Current @ 25°C: 2.2A (Tc)
Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Gate Charge: 17nC @ 10V
Maximum Rds On @ Id,Vgs: 270 mOhm @ 1.2A, 10V
Supply and Demand Status: Limited
Applications: Industrial and power management
