The supply and demand status is limited, and the component is used in industrial, power management, communications and networking, and automotive applications.

• Packaging: reel-TR
• Mounting: SMD (SMT)
• Technology: MOSFET
• Polarity: N-Channel
• Power Dissipation (max): 1.9W (Ta)
• Drive Voltage: 6V (max Rds On) and 10V (min Rds On)
• Temperature Range for Operation: -55°C to 150°C (TJ)
• Case / Package: PowerPAK SO-8
• Dimension: PowerPAK SO-8
• Drain-Source Breakdown Voltage: 100V
• Continuous Drain Current at 25°C: 5A (Ta)
• Gate-Source Threshold Voltage: 4V @ 250μA
• Max Gate Charge: 30nC @ 10V
• Maximum Gate-Source Voltage: ±20V
• Maximum Rds On at Id, Vgs: 34 mOhm @ 7.8A, 10V
• Quantity per Package: 3k pcs
