SI7852DP-T1-E3 Vishay SI7852DP-T1-E3 Real Image SI7852DP-T1-E3 Real Image1 SI7852DP-T1-E3 Real Image2 SI7852DP-T1-E3 label picture 2 SI7852DP-T1-E3 label picture 3 SI7852DP-T1-E3 real image SI7852DP-T1-E3 real image 2
Same model may have multiple batches, images only for reference.
SI7852DP-T1-E3 Vishay SI7852DP-T1-E3 Real Image SI7852DP-T1-E3 Real Image1 SI7852DP-T1-E3 Real Image2 SI7852DP-T1-E3 label picture 2 SI7852DP-T1-E3 label picture 3 SI7852DP-T1-E3 real image SI7852DP-T1-E3 real image 2
SI7852DP-T1-E3 Vishay SI7852DP-T1-E3 Real Image SI7852DP-T1-E3 Real Image1 SI7852DP-T1-E3 Real Image2 SI7852DP-T1-E3 label picture 2 SI7852DP-T1-E3 label picture 3 SI7852DP-T1-E3 real image SI7852DP-T1-E3 real image 2
Same model may have multiple batches, images only for reference.

SI7852DP-T1-E3

Part No SI7852DP-T1-E3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 80V 7.6A 8-Pin PowerPAK SO EP T/R / MOSFET N-CH 80V 7.6A PPAK SO-8
Datasheet
SI7852DP-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 80V
Continuous Drain Current at 25°C 7.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 2V @ 250μA (Min)
Max Gate Charge 41nC @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.9W (Ta)
Maximum Rds On at Id,Vgs 16.5 mOhm @ 10A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PowerPAK SO-8
Dimension PowerPAK SO-8
Win Source Part Number 028674-SI7852DP-T1-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Quantity per package 3k pcs
Family Name Si7852DP
Introduction Date May 23, 2001
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian SI7852DP-T1-E3 CAD Model

Description

The Vishay 028674-SI7852DP-T1-E3 is a high-popularity electronic component suitable for use in discrete semiconductor products.

  • Polarity: N-channel
  • Power Dissipation: 1.9W (Ta)
  • Family Name: Si7852DP
  • Manufacturer: Vishay
  • Supply and Demand Status: limited
  • Suitable for: industrial power management applications
