SMCJ30CA-E3/57T Vishay SMCJ30CA-E3/57T real image SMCJ30CA-E3/57T label picture
Same model may have multiple batches, images only for reference.
SMCJ30CA-E3/57T Vishay SMCJ30CA-E3/57T real image SMCJ30CA-E3/57T label picture
SMCJ30CA-E3/57T Vishay SMCJ30CA-E3/57T real image SMCJ30CA-E3/57T label picture
Same model may have multiple batches, images only for reference.

SMCJ30CA-E3/57T

Part No SMCJ30CA-E3/57T
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS Diode Single Bi-Dir 30V 1.5KW 2-Pin SMC T/R / TVS DIODE 30VWM 48.4VC SMC
Datasheet
SMCJ30CA-E3/57T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 30V
Minimum Breakdown Voltage 33.3V
Max Clamping Voltage 48.4V
Peak Pulse Current(Ippm) 31A
Power Dissipation - Pd 1500W (1.5kW)
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AB (SMCJ)
Win Source Part Number 029310-SMCJ30CA-E3/57T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 850
Family Name SMCJ30CA
Introduction Date January 29, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SMCJ30CA-E3/57T CAD Model

Description

The Vishay 029310-SMCJ30CA-E3/57T zener diode is a surface-mount device designed for general-purpose applications.

  • Application: General-Purpose
  • Mounting: Surface-Mount
  • Stand-Off Voltage: 30V
  • Minimum Breakdown Voltage: 33.3V
  • Maximum Clamping Voltage: 48.4V
  • Peak Pulse Current: 31A
  • Power Dissipation: 1500W (1.5kW)
  • Operating Temperature: -55°C to 150°C
  • Package: DO-214AB (SMCJ)
  • Compliance: Halogen-Free
  • Status: Common and widely used
  • Alternative Parts: MXSMCG30CAE3TR, SMCG30CAe3, SMLG30CTR, and SMLG30C/TR13
