Same model may have multiple batches, images only for reference.

SUD40N10-25-E3

Name: SUD40N10-25-E3
Brand: Vishay
SKU: 349131
Availability: InStock
Rating: 4.91 (48 reviews)

Get a Quote

Part No	SUD40N10-25-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 100V 40A 3-Pin(2+Tab) DPAK / MOSFET N-CH 100V 40A TO252
Datasheet	SUD40N10-25-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	100V
Continuous Drain Current at 25°C	40A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	60nC @ 10V
Max Input Capacitance	2400pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3W (Ta), 136W (Tc)
Maximum Rds On at Id,Vgs	25 mOhm @ 40A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-252, (D-Pak)
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	123301-SUD40N10-25-E3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Power Management
Family Name	SUD40N10-25
Introduction Date	April 26, 2000
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian SUD40N10-25-E3 CAD Model

Alternative Products

Description

This electronic component is also manufactured by Vishay and has a Win Source Part Number of 123301-SUD40N10-25-E3.

Manufacturer: Vishay
Win Source Part Number: 123301-SUD40N10-25-E3
Type: MOSFET
Polarity: N-channel
Power Dissipation: 3W (Ta) or 136W (Tc)
Category: Discrete Semiconductor Products
Popularity: High
Application: Power Management
Alternative Parts: DMNH10H028SK3Q-13, FDD3670_NL, FDD3670-Q, and DMNH10H028SK3-13
