Same model may have multiple batches, images only for reference.

SUD50P04-13L-GE3

Name: SUD50P04-13L-GE3
Brand: Vishay
SKU: 349194
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	SUD50P04-13L-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 40V 60A DPAK
Datasheet	SUD50P04-13L-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Obsolete(EOL)
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	60A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	95nC @ 10V
Max Input Capacitance	3120pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3W (Ta), 93.7W (Tc)
Maximum Rds On at Id,Vgs	13 mOhm @ 30A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	TO-252, (D-Pak)
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	132319-SUD50P04-13L-GE3
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian SUD50P04-13L-GE3 CAD Model

Alternative Products

Description

The Vishay SUD50P04-13L-GE3 is a P-channel MOSFET that offers a drain-source breakdown voltage of 40V and a continuous drain current of 60A.

On-Resistance: low on-resistance of 13 mOhm
Maximum Gate Charge: 95nC
Operating Temperature Range: -55°C to 175°C
Popularity: medium
Supply and Demand Status: limited
