It is essential to provide fit-for-use housings for modern electronic components. Setting and control functions must be easily carried out and technical requirements with respect to heat dissipation and EMV properties should be supported. An ideal design saves space and wiring costs in the switchgear cabinet. In addition, ergonomics and design are becoming increasingly important for highquality electronic products. These are the criteria that led to the development of WAVEBOX. Simplified production methods (shaft soldering, SMD) ensure cost-savings for the customer. The WAVEBOX is characterised by:
• Optimum width for any application (12.5 mm, 17.5 mm, 22.5 mm)
• Large component assembly surface; SMDs can be mounted on the solder side
• UL94 flammability class V2
• No tools required for assembly
• Plug-in printed circuit board
• Plug-in cross-connection via ZQV 2.5 N
• Hinged, transparent cover
• BLZ 5.08 screw/plug and socket connector
• BLFZ 5.08 optional tension clamp/plug and socket connector
• Marking option with WS tags
• Mounts onto TS 35
