1794990000

Get a Quote

Part No	1794990000
Manufacturer	Weidmuller
Catalog	Headers, Plugs and Sockets
Description	TERM BLOCK HDR 32POS 90DEG 3.5MM / 32 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) 90°, Right Angle Through Hole
Datasheet	1794990000 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Terminal Blocks>Headers, Plugs and Sockets
Mfr	Weidmuller
Series	Omnimate S2L
Package	Bulk
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	32
Positions Per Level	16
Number of Levels	2
Pitch	0.138" (3.50mm)
Header Orientation	90°, Right Angle
Plug Wire Entry	-
Termination Style	Solder
Mounting Type	Through Hole
Current - IEC	10A
Voltage - IEC	160 V
Current - UL	10 A
Voltage - UL	150 V
Wire Gauge or Range - AWG	-
Wire Gauge or Range - mm2	-
Color	Black
Temperature Range - Operating	-50°C ~ 100°C
Contact Mating Finish	Tin
Features	Mating Flange, Solder Retention
Material Flammability Rating	UL94 V-0
Ingress Protection	IP10
Screw Size	-
Torque - Screw	-
Wire Strip Length	-
Contact Material	Copper Alloy
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Contact Tail Length	0.126" (3.20mm)
Insulation Height	0.452" (11.48mm)
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Standard Package	24 pcs
Win Source Part Number	1380579-1794990000
Ultra Librarian 3D Model	Ultra Librarian 1794990000 CAD Model

Alternative Products

Description

The 1380579-1794990000 is a male header connector from the Omnimate S2L series by Weidmuller.

Series: Omnimate S2L
Type: Shrouded Header with 4-Sided Male Pins
Positions: 32
Pitch: 0.138" (3.50mm)
Orientation: Right Angle (90 degrees)
Mounting: Through-Hole
Termination Style: Solder
Current Rating (IEC): 10A
Current Rating (UL): 10A
Voltage (IEC): 160V
Voltage (UL): 150V
Contact Material: Copper Alloy with Tin Finish
Housing Material: Liquid Crystal Polymer (LCP), Glass Filled
Color: Black
Ingress Protection: IP10
Temperature Range: -50°C to 100°C
Package: Bulk of 24 pcs
