Same model may have multiple batches, images only for reference.

744774147

Name: 744774147
Brand: Wurth Electronics Inc
SKU: 857553
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	744774147
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	FIXED IND 47UH 860MA 370MOHM SMD
Datasheet	744774147 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Wurth Electronics Inc
Series	WE-PD2
Package	Tape & Reel
Product Status	Active
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	47 µH
Tolerance	±15%
Current Rating (Amps)	860 mA
Current - Saturation (Isat)	1A
Shielding	Unshielded
DC Resistance (DCR)	370mOhm Max
Frequency - Self Resonant	11.5MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	10 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.228" L x 0.205" W (5.80mm x 5.20mm)
Height - Seated (Max)	0.191" (4.85mm)
Standard Package	1,500 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	857553-744774147
Ultra Librarian 3D Model	Ultra Librarian 744774147 CAD Model

Alternative Products

Description

The WE-PD2 series from Wurth Electronics Inc is a drum core, wirewound inductor designed for various electronic applications.

Size: 0.228" L x 0.205" W (5.80mm x 5.20mm)
Inductance: 47 µH
Tolerance: ±15%
Height: 0.191" (4.85mm) max seated
DC Resistance (DCR): 370mOhm
Operating Temperature: -40°C to 125°C
Mounting Type: Surface Mount
Package: Nonstandard
Shielding: Unshielded
Material: Ferrite
Current Rating: 860 mA
Saturation Current (Isat): 1A
