3659/09 100SF3M
Same model may have multiple batches, images only for reference.

3659/09 100SF

Part No 3659/09 100SF
Manufacturer 3M
Catalog Flat Ribbon Cables
Description CABLE RIBBON 9COND 0.05 BLACK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number Cross
Manufacturer 3M
Category Cables, Wires Flat Ribbon Cables
Package Spool
Product Status Active
Cable Type Flat Cable, Round Jacket
Pitch 0.050" (1.27mm)
Conductor Strand 7 Strands / 36 AWG
Shielding Shielded
Ribbon Width 0.402" (10.20mm)
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Win Source Part Number WS1208187-3659/09 100SF
Ultra Librarian 3D Model Ultra Librarian 3659/09 100SF CAD Model

Description

• Round construction permits easier routing • 28 AWG wire on .050 inch pitch permits mass termination to broad line of IDC connectors • Continuous split/bond repeat allows for mass termination on 2.4 inch centers (approximate) • Primary cable is zippable for branching or discrete terminations • Meets external wiring requirements of National Electrical Code, Article 725 (CL2) • UL listed for USA and Canadian markets • Dual shielding provides 35 db average shielding effectiveness<br /> • See Regulatory Information Appendix (RIA) for chemical compliance information (RIA E1 & C1 apply)
