4506 Welwyn Components Limited
Same model may have multiple batches, images only for reference.

4506

Part No 4506
Manufacturer Adafruit Industries LLC
Catalog Evaluation Boards - Expansion Boards
Description RPI COLOR TFT BONNET + JOYSTICK
Datasheet
4506 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers - Evaluation Boards - Expansion Boards, Daughter Cards
Mfr Adafruit Industries LLC
Package Bulk
Product Status Active
Platform Raspberry Pi
Type Display
Function LCD 1.3"
Utilized IC / Part ST7789
Contents Board(s)
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8524.91.1000
Win Source Part Number 546045-4506
Ultra Librarian 3D Model Ultra Librarian 4506 CAD Model

Description

The 546045-4506 is an expansion board designed for development and evaluation purposes.

  • Compatibility: Raspberry Pi platform
  • Display: LCD 1.3" display
  • Package: Bulk
  • Components: Includes all necessary components for operation
  • IC/Part: ST7789
  • Manufacturer: Adafruit Industries LLC
  • Status: Active
  • Export Control: Complies with export control regulations
  • MSL: 1 (unlimited shelf life)
