AO4752 Real Image AO4752 real image15103
Same model may have multiple batches, images only for reference.
AO4752 Real Image AO4752 real image15103
AO4752 Real Image AO4752 real image15103
Same model may have multiple batches, images only for reference.

AO4752

Part No AO4752
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 15A 8SOIC
Datasheet
AO4752 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 15A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 15nC @ 10V
Max Input Capacitance 605pF @ 15V
Maximum Gate-Source Voltage ±20V
FET Feature Schottky Diode (Body)
Power Dissipation (Max) 3.1W (Ta)
Maximum Rds On at Id,Vgs 8.8 mOhm @ 15A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 1016807-AO4752
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian AO4752 CAD Model

Description

The MOSFET is a N-Channel polarity electronic component used in discrete semiconductor products. Manufactured by Alpha & Omega Semiconductor Inc.

  • Polarity: N-Channel
  • Maximum Power Dissipation: 3.1W (Ta)
  • Packaging: Reel - TR
  • Mounting Type: SMD (SMT)
  • Drive Voltage: 4.5V, 10V
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current @ 25°C: 15A (Ta)
  • Gate-Source Threshold Voltage: 2.5V @ 250μA
  • Maximum Gate Charge: 15nC @ 10V
  • Maximum Rds On @ Id,Vgs: 8.8 mOhm @ 15A, 10V
