AO7401 Real Image AO7401 Real Image
Same model may have multiple batches, images only for reference.
AO7401 Real Image AO7401 Real Image
AO7401 Real Image AO7401 Real Image
Same model may have multiple batches, images only for reference.

AO7401

Part No AO7401
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 30V 1.4A SC70-3
Datasheet
AO7401 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 1.4A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 10V
Gate-Source Threshold Voltage 1.4V @ 250μA
Max Gate Charge 5.06nC @ 4.5V
Max Input Capacitance 409pF @ 15V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 350mW (Ta)
Maximum Rds On at Id,Vgs 150 mOhm @ 1.2A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-3
Dimension SC-70, SOT-323
Win Source Part Number 009779-AO7401
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AO7401 CAD Model

Description

AO7401 Features & Benefits

  • Low on-resistance
  • High-speed operation
  • SMD package

The AO7401 offers a low on-resistance characteristic, ensuring efficient current conduction for demanding applications. Its high-speed operation is perfect for applications requiring rapid switching and minimal power loss.

Applications

  • Switching regulators
  • High-efficiency power stages
  • Load management
  • Portable power tools

This device is optimized for use in circuits where efficient power delivery and management are paramount.
