PRFS-P5022-008 Anadigics, Inc
Same model may have multiple batches, images only for reference.

PRFS-P5022-008

Part No PRFS-P5022-008
Manufacturer Anadigics, Inc
Catalog RF Amplifiers
Description IC AMP GPS 5.15-5.85GHZ 12LPCC
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Amplifiers
Mfr Anadigics, Inc
Package Bulk
Product Status Active
Frequency 5.15GHz ~ 5.85GHz
P1dB 25dBm
Gain 23dB
Noise Figure 7.5dB
RF Type General Purpose
Voltage - Supply 3.3V
Current - Supply 175mA
Test Frequency 5.15GHz ~ 5.85GHz
Mounting Type Surface Mount
Package / Case 12-TFQFN Exposed Pad
Supplier Device Package 12-LPCC (3x3)
Standard Package 1,000 pcs
MSL Level 3 (168 Hours)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 280448-PRFS-P5022-008
Ultra Librarian 3D Model Ultra Librarian PRFS-P5022-008 CAD Model

Description

The 280448-PRFS-P5022-008 is an RF amplifier designed for general-purpose applications.

  • Test frequency range: 5.15GHz to 5.85GHz
  • Gain: 23dB
  • Noise figure: 7.5dB
  • Supply voltage: 3.3V
  • Current consumption: 175mA
  • P1dB: 25dBm
  • Suitable for: surface mount applications
  • Package: 12-TFQFN exposed pad
  • Supplier device package: 12-LPCC (3x3)
  • Product status: active
  • Standard package: 1,000 pieces
  • ECCN: EAR99
  • MSL level: 3
  • HTSUS code: 8542.33.0001
  • Manufacturer: Anadigics, Inc.
