ADA4075-2ARZ-RL

Part No ADA4075-2ARZ-RL
Manufacturer Analog Devices Inc.
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 6.5MHZ 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 12 V/μs
Gain Bandwidth Product (GBP) 6.5MHz
Current - Input Bias 30nA
Voltage - Input Offset 200μV
Operating Supply Current 1.8mA
Channel Output Current 40mA
Supply Voltage - Operating ±4.5 V to 18 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 138182-ADA4075-2ARZ-RL
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADA4075-2ARZ-RL CAD Model

Description

The ADA4075-2ARZ-RL from Analog Devices Inc. is a high-performance, dual operational amplifier that offers precision, low noise, and low input bias current. This operational amplifier is designed for a wide range of applications, including medical instruments, sensor conditioning, and professional audio equipment, where maintaining signal fidelity is of utmost importance.

Key Features:

  • Low Offset Voltage: The device features a low offset voltage, which ensures accurate signal amplification without significant deviation from the intended input.
  • Low Noise: With its low noise performance, the ADA4075-2ARZ-RL is ideal for applications requiring a high signal-to-noise ratio, preserving the integrity of the original signal.
  • High Precision: The operational amplifier provides high precision, which is critical in measurement and instrumentation applications.
  • Dual Amplifier: The dual configuration allows for flexible circuit designs, including differential amplifiers, active filters, and more.
  • Wide Supply Range: It operates over a wide supply voltage range, accommodating various power requirements for different systems.
  • Low Input Bias Current: The low input bias current minimizes errors in applications with high source impedance, ensuring reliable performance.

Product Specifications:

Parameter Value
Number of Channels 2
Supply Voltage ±2.5V to ±18V
Operating Temperature -40°C to +125°C
Package / Case SOIC-8
Mounting Type Surface Mount

The ADA4075-2ARZ-RL is available in a small outline integrated circuit (SOIC) package, which is suitable for space-constrained applications. Its robust design ensures reliable operation even in harsh environments, making it a versatile choice for a broad range of electronic systems. Analog Devices Inc. is known for its commitment to high-quality components, and the ADA4075-2ARZ-RL operational amplifier is no exception, providing both performance and reliability for your critical design requirements.
